Integrated Inverter Step-up Transformer System

IBC-1500V-5MW

IBC-1500V-6.25MW

IBC-1500V-6.9MW

Integrated Inverter Step-up Transformer System, suitable for large energy storage power station systems

Integrated Inverter Step-up Transformer System

IBC-1500V-5MW

IBC-1500V-6.25MW

IBC-1500V-6.9MW

Integrated Inverter Step-up Transformer System, suitable for large energy storage power station systems

产品特点

Product Features

Product Features

Highly Integrated

Modular design improves space utilization
Pre-installed and pre-engineered to reduce on-site work
Easy to install and transport
Efficient Reliable

IP 54 protection level, adapt to vairous environments
Inverter and transformer unit optimized to improve system eﬀciency
Energy Saving Cost Down

Three level topology, with maximum conversion eﬃciency of 98.5%
High integration and small footprint. Easy to transport and install, reducing on-site construction costs
Grid-tied

Equipped with LVRT and HVRT.
Equipped with active and reactive four-quadrant adjustment function.
Fast power response (<10ms).

Download Contact

规格参数

Parameters

Parameters

IBC-1500V-5MW IBC-1500V-6.25MW IBC-1500V-6.9MW

Max DC power :
5000/6250/6900kW
DC voltage range :
1000~1500V
DC input channels :
2/4/16/24
Rated DC Current :
5000/6250/6900A
AC voltage range :
586~759V
Maximum AC Power :
5500/6875/7590kVA
Rated AC Current :
4184/5230/5774A
Rated AC voltage :
690V
Grid frequency range :
50/60Hz
Output current (THD) :
<3% (Rated power)
Transformer type :
Dry/Oil
Voltage transformation ratio :
0.69kV/35kV
Maximum Efficiency :
98.5%
Protection level :
IP 54
Allowable environment temperature :
-35℃~+60℃

Max DC power :
5000/6250/6900kW
DC voltage range :
1000~1500V
DC input channels :
2/4/16/24
Rated DC Current :
5000/6250/6900A
AC voltage range :
586~759V
Maximum AC Power :
5500/6875/7590kVA
Rated AC Current :
4184/5230/5774A
Rated AC voltage :
690V
Grid frequency range :
50/60Hz
Output current (THD) :
<3% (Rated power)
Transformer type :
Dry/Oil
Voltage transformation ratio :
0.69kV/35kV
Maximum Efficiency :
98.5%
Protection level :
IP 54
Allowable environment temperature :
-35℃~+60℃

Max DC power :
5000/6250/6900kW
DC voltage range :
1000~1500V
DC input channels :
2/4/16/24
Rated DC Current :
5000/6250/6900A
AC voltage range :
586~759V
Maximum AC Power :
5500/6875/7590kVA
Rated AC Current :
4184/5230/5774A
Rated AC voltage :
690V
Grid frequency range :
50/60Hz
Output current (THD) :
<3% (Rated power)
Transformer type :
Dry/Oil
Voltage transformation ratio :
0.69kV/35kV
Maximum Efficiency :
98.5%
Protection level :
IP 54
Allowable environment temperature :
-35℃~+60℃
