PCS Module

HYNN's 1500V energy storage inverter, IP65 protection, efficient and stable, supports overload and high temperature. One cluster, one management, solves the problem of parallel connection of multiple clusters of batteries, integrates charging and discharging management, real-time monitoring, and achieves intelligent energy storage.

PCS Module

HYNN's 1500V energy storage inverter, IP65 protection, efficient and stable, supports overload and high temperature. One cluster, one management, solves the problem of parallel connection of multiple clusters of batteries, integrates charging and discharging management, real-time monitoring, and achieves intelligent energy storage.

产品特点

Product Features
Product Features
Download Contact

规格参数

Parameters
Parameters
HYNN-PCS215-1500M
  • Max DC input voltage :
    1500Vdc
  • DC input voltage range :
    1000~1500Vdc
  • Max DC input current :
    237A
  • Precision of voltage regulation :
    ±1%
  • Precision of current regulation :
    ±1%
  • DC current ripple :
    ≤2%
  • PCS topology :
    Single layer
  • Rated AC output power :
    215kW
  • Rated AC output current :
    180A
  • Rated AC output voltage :
    690Vac
  • AC output voltage range :
    621~759Vac (586.5~759V)
  • Rated grid frequency :
    50Hz/60Hz
  • THD (Rated power) :
    <3%
  • Power factor :
    ≥0.99 (Rated power)
  • Power factor adjustable range :
    -1 ～1
  • Max efficiency :
    99%
  • System voltage standard :
    IT690V
  • Protection level :
    IP 65
  • Cooling method :
    Natural heat dissipation/liquid cooling
  • Allowable environment temperature :
    -30℃～+60℃
  • Allowable relative humidity :
    ≤95% (No dew)
  • Allowable max altitude :
    4000m (Capacity should be decreased if over 2000)
  • Communication :
    Ethernet / RS485 / CAN
  • Modbus & Protocol :
    ModbusTCP/RTU
  • Size (W×L×H) :
    700*270*835mm
  • Weight :
    110kg
  • Reference standards :
    IEC62477, IEC 61000, GB/T 34120, GB/T 34133
